POS-02
Two-Axis Trunnion Table
2 axes: tilt and rotation
Drag to rotate the model; scroll or pinch to zoom.
What it is
The faceplate hangs in a cradle between two columns; it tilts and rotates. The tilt axis runs close to the part's centre of gravity.
Typical parts
Assemblies with welds on several sides: every weld is turned to the flat position.
